Snake Spacers

Snake Spacers

A lightweight but strong continuous line spacer with a corrugated profile providing an extremely stable
support for mesh reinforcement.
Approved according to DBV specification.
Product Code Height (mm) Length (mtr) Weight (kg/mtr) Pack Size (mtr) Pallet Size (mtr)
ZZ050DBV 50 2 0.195 1200 2400
ZZ060DBV 60 2 0.203 1200 2400
ZZ070DBV 70 2 0.210 1200 2400
ZZ080DBV 80 2 0.217 1000 2000
ZZ090DBV 90 2 0.223 1000 2000
ZZ100DBV 100 2 0.230 1000 2000
ZZ110DBV 110 2 0.238 800 1600
ZZ120DBV 120 2 0.244 800 1600
ZZ130DBV 130 2 0.260 800 1600
ZZ140DBV 140 2 0.272 600 1200
ZZ150DBV 150 2 0.278 600 1200
ZZ160DBV 160 2 0.285 600 1200
ZZ180DBV 180 2 0.338 600 1200
ZZ200DBV 200 2 0.365 400 800
ZZ220DBV 220 2 0.468 400 800
ZZ240DBV 240 2 0.486 400 800
ZZ260DBV 260 2 0.576 200 600
ZZ280DBV 280 2 0.599 150 450
ZZ300DBV 300 2 0.621 150 450
ZZ320DBV 320 2 0.711 150 300
ZZ340DBV 340 2 0.737 150 300
ZZ360DBV 360 2 0.762 150 300
ZZ380DBV 380 2 0.788 150 300
ZZ400DBV 400 2 0.813 150 300
