High Chairs
Standard High Chairs
Intersig's High Chairs are designed for supporting bars and mesh on site and in the precast factory. Their unique design eliminates any danger of puncturing the Damp Proof Membrane on ground floor slabs. Also known as Hystools and Deck Chairs.
| Product Code | Height (mm) | Top Bar (mm) | Stirrup (mm) | Bottom Bar (mm) | Length (mtr) | Weight (kg/mtr) | Pack Size (mtr) |
|---|---|---|---|---|---|---|---|
| AL050 | 50 | 4.0 | 2.8 | 2.8 | 2 | 0.310 | 500 |
| AL060 | 60 | 4.0 | 2.8 | 2.8 | 2 | 0.315 | 500 |
| AL070 | 70 | 4.0 | 2.8 | 2.8 | 2 | 0.320 | 500 |
| AL075 | 75 | 4.0 | 2.8 | 2.8 | 2 | 0.324 | 500 |
| AL090 | 90 | 4.0 | 2.8 | 2.8 | 2 | 0.333 | 500 |
| AL100 | 100 | 4.0 | 2.8 | 2.8 | 2 | 0.340 | 500 |
| AL105 | 105 | 4.0 | 2.8 | 2.8 | 2 | 0.344 | 500 |
| AL120 | 120 | 4.0 | 2.8 | 2.8 | 2 | 0.355 | 500 |
| AL130 | 130 | 4.0 | 2.8 | 2.8 | 2 | 0.362 | 500 |
| AL135 | 135 | 4.00 | 2.8 | 2.8 | 2 | 0.366 | 500 |
| AL150 | 150 | 4.00 | 2.8 | 2.8 | 2 | 0.379 | 500 |
| AL160 | 160 | 4.5 | 3.0 | 3.0 | 2 | 0.457 | 500 |
| AL165 | 165 | 4.5 | 3.0 | 3.0 | 2 | 0.462 | 500 |
| AL170 | 170 | 4.5 | 3.0 | 3.0 | 2 | 0.467 | 500 |
| AL180 | 180 | 4.5 | 3.0 | 3.0 | 2 | 0.477 | 500 |
| AL190 | 190 | 4.5 | 3.0 | 3.0 | 2 | 0.486 | 500 |
| AL200 | 200 | 4.5 | 3.0 | 3.0 | 2 | 0.497 | 500 |
| AL220 | 220 | 4.5 | 4.0 | 3.0 | 2 | 0.735 | 200 |
| AL250 | 250 | 4.5 | 4.0 | 3.0 | 2 | 0.790 | 200 |
| AL280 | 280 | 4.5 | 4.0 | 3.0 | 2 | 0.846 | 200 |
| AL300 | 300 | 4.5 | 4.0 | 3.0 | 2 | 0.884 | 200 |
