Cast-in Channel T- Bolts

T-Bolts

Cast-in Channel T-Bolts

Our T-Bolts are specifically designed for use with the appropriate channel section.

They are available galvanised, with a grade 8.8 electroplated finish as standard as well as a stainless steel version.

Toothed T-Bolts are available upon request.

Product Code (Galvanised)	Product Code (Stainless Steel)	Profile	Thread (M)	Length (mm)	Tightening Torque (Nm)
TB28151050G	TB28151050SS	28/15	10	50	13
TB38171250G	TB38171250SS	38/17	12	50	25
TB38171280G	TB38171280SS	38/17	12	80	25
TB38171650G	TB38171650SS	38/17	16	50	25
TB38171680G	TB38171680SS	38/17	16	80	25
TB40251250G	TB40251250SS	40/25	12	50	45
TB40251280G	TB40251280SS	40/25	12	80	45
TB40251650G	TB40251650SS	40/25	16	50	45
TB40251680G	TB40251680SS	40/25	16	80	45
TB49301650G	TB49301650SS	49/30	16	50	60
TB49301680G	TB49301680SS	49/30	16	80	60
TB493016100G	TB493016100SS	49/30	16	100	60
TB49302050G	TB49302050SS	49/30	20	50	60
TB49302080G	TB49302080SS	49/30	20	80	60
TB493020100G	TB493020100SS	49/30	20	100	60
TB54331650G	TB54331650SS	54/33	16	50	60
TB54331680G	TB54331680SS	54/33	16	80	60
TB543316100G	TB543316100SS	54/33	16	100	60
TB54332050G	TB54332050SS	54/33	20	50	60
TB54332080G	TB54332080SS	54/33	20	80	60
TB543320100G	TB543320100SS	54/33	20	100	60
TB72492080G	TB72492080SS	72/49	20	80	120
TB724920100G	TB7249100SS	72/49	20	100	120
