PIR Standard Insulation Boards

PIR Insulation Boards

Standard foil back Insulation Board is manufactured from rigid polyisocyanurate (PIR) using a blowing agent that has zero ozone depletion potential (zero ODP) and low global warming potential (GWP).

Slide title

Profile:
40/25, 49/30, 54/33 & 72/49

Button

Product Code	Thickness (mm)	Width (mm)	Length (mm)	Thermal Conductivity (w/mk)	RD - Value (m2/KW)
PIR030	30	1200	2400	0.022	1.35
PIR040	40	1200	2400	0.022	1.8
PIR050	50	1200	2400	0.022	2.25
PIR060	60	1200	2400	0.022	2.7
PIR070	70	1200	2400	0.022	3.15
PIR080	80	1200	2400	0.022	3.6
PIR090	90	1200	2400	0.022	4.05
PIR100	100	1200	2400	0.022	4.5
PIR110	110	1200	2400	0.022	5
PIR130	130	1200	2400	0.022	5.45
PIR140	140	1200	2400	0.022	5.9
PIR150	150	1200	2400	0.022	6.35
PIR165	165	1200	2400	0.022	7.5
PIR200	200	1200	2400	0.022	9.05
