Heavy Duty High Chairs
Heavy Duty High Chairs
Intersig's heavy duty high chairs are manufactured with larger wires for supporting heavier bars and mesh on site and in the precast factory. Their unique design eliminates any danger of puncturing the Damp Proof Membrane on ground floor slabs. Also known as Hystools and Deck Chairs.
Approved according to DBV specification.
| Product Code | Height (mm) | Top Bar (mm) | Stirrup (mm) | Bottom Bar (mm) | Length (mtr) | Weight (kg/mtr) | Pack Size (mtr) |
|---|---|---|---|---|---|---|---|
| A050 | 50 | 4.7 | 3.3 | 3.3 | 2 | 0.430 | 500 |
| A060 | 60 | 4.7 | 3.3 | 3.3 | 2 | 0.435 | 500 |
| A075 | 75 | 4.7 | 3.3 | 3.3 | 2 | 0.445 | 500 |
| A090 | 90 | 4.7 | 3.3 | 3.3 | 2 | 0.460 | 500 |
| A105 | 105 | 4.7 | 3.3 | 3.3 | 2 | 0.470 | 500 |
| A120 | 120 | 4.7 | 3.3 | 3.3 | 2 | 0.485 | 500 |
| A135 | 135 | 4.7 | 3.3 | 3.3 | 2 | 0.500 | 500 |
| A150 | 150 | 4.7 | 3.3 | 3.3 | 2 | 0.515 | 500 |
| A165 | 165 | 4.7 | 3.3 | 3.3 | 2 | 0.535 | 500 |
| A180 | 180 | 4.7 | 3.3 | 3.3 | 2 | 0.550 | 500 |
| A200 | 200 | 4.7 | 3.3 | 3.3 | 2 | 0.575 | 500 |
| A220 | 220 | 4.7 | 4.0 | 3.3 | 2 | 0.755 | 200 |
| A230 | 230 | 4.7 | 4.0 | 3.3 | 2 | 0.770 | 200 |
| A250 | 250 | 4.7 | 4.0 | 3.3 | 2 | 0.810 | 200 |
| A270 | 270 | 4.7 | 5.0 | 4.0 | 2 | 1.259 | 200 |
| A280 | 280 | 4.7 | 5.0 | 4.0 | 2 | 1.260 | 200 |
| A300 | 300 | 4.7 | 5.0 | 4.0 | 2 | 1.320 | 200 |
| A320 | 320 | 6.0 | 5.0 | 5.0 | 2 | 1.575 | 100 |
| A340 | 340 | 6.0 | 5.0 | 5.0 | 2 | 1.635 | 100 |
| A360 | 360 | 6.0 | 5.0 | 5.0 | 2 | 1.695 | 100 |
| A380 | 380 | 6.0 | 5.0 | 5.0 | 2 | 1.750 | 100 |
| A400 | 400 | 6.0 | 5.0 | 5.0 | 2 | 1.810 | 100 |
| A450 | 450 | 5.0 | 5.0 | 5.0 | 2 | 1.230 | 100 |
