EVL Connecting Box
EVL Connecting Box
EVL Connecting Boxes are single wire loops for connecting precast wall panels to each other or to a column. Connection Loops make wall installation easy, just open the cover and bend the loop into final operating position.
| Product Code | Inside Loop (mm) | Box Length (mm) | Box Width (mm) | Box Height (mm) | Pack Size | Pallet Size |
|---|---|---|---|---|---|---|
| EVL060 | 60 | 160 | 50 | 20 | 100 | 1800 |
| EVL080 | 80 | 160 | 50 | 20 | 100 | 1800 |
| EVL100 | 100 | 160 | 50 | 20 | 100 | 1800 |
| EVL120 | 120 | 160 | 50 | 20 | 100 | 1800 |
| EVL140 | 140 | 200 | 70 | 30 | 100 | 1200 |
