Spread Anchor Ring Clutch

Spread Anchor Ring Clutch

The Ring Clutch is an all cast item specially designed not only to fit the Spread Anchor of its related safe working load but also to match the pocket created by the corresponding capacity Rubber Former. In this way, one can be assured that no two lifting capacities can be utilised in the lifting process. The Ring Clutches are individually tested and come uniquely stamped with a corresponding lifting test certificate.

Product Code Load Group (kg) Length (mm)
LASRC025 700 - 2500 259
LASRC050 3000 - 5000 325
LASRC100 5300 - 10000 431
LASRC260 12500 - 26000 620
  • Data Sheet

    Guidance on Choice of Anchor (Download)

    Spread Anchor Ring Clutch Data Sheet (Download)

  • Technical Manual

    Spread Anchor System Technical Manual (Download)

  • Certificates

    UKCA Declaration of Conformance (Download)

    EU CE Declaration of Conformance (Download)

    UK Test Certificate Example (Download)
