Metal Edge Formwork is lightweight and therefore quick and easy to install onto bearing inner leaves and/or party walls. The best possible results are achieved in combination with the universal corner pieces and the quick-acting tensioners. The metal formwork is a “lost” formwork, so the need to dismantle afterwards no longer exist. Making your work far more efficient. The metal formwork has been made of sendzimir galvanised steel (SV), available from stock in 0.7mm and up to 2.0mm on request. The various types allow
trouble-free application of the metal formwork for just about any floor thickness.
Product Code | Height (mm) | Flange (mm) | Thickness (mm) | Length (mtr) | Pallet Size (mtr) |
---|---|---|---|---|---|
OEF150 | 150 | 55 | 0.7 | 2 | 600 |
OEF160 | 160 | 55 | 0.7 | 2 | 600 |
OEF170 | 170 | 55 | 0.7 | 2 | 600 |
OEF180 | 180 | 55 | 0.7 | 2 | 600 |
OEF190 | 190 | 55 | 0.7 | 2 | 600 |
OEF200 | 200 | 55 | 0.7 | 2 | 600 |
OEF210 | 210 | 55 | 0.7 | 2 | 400 |
OEF220 | 220 | 55 | 0.7 | 2 | 400 |
OEF230 | 230 | 55 | 0.7 | 2 | 400 |
OEF240 | 240 | 55 | 0.7 | 2 | 400 |
OEF250 | 250 | 55 | 0.7 | 2 | 400 |
OEF260 | 260 | 55 | 0.8 | 2 | 400 |
OEF270 | 270 | 55 | 0.8 | 2 | 400 |
OEF280 | 280 | 55 | 0.8 | 2 | 400 |
OEF290 | 290 | 55 | 0.8 | 2 | 400 |
OEF300 | 300 | 55 | 0.8 | 2 | 300 |
OEF310 | 310 | 60 | 0.8 | 2 | 300 |
OEF320 | 320 | 60 | 0.8 | 2 | 300 |
OEF330 | 330 | 60 | 0.8 | 2 | 300 |
OEF340 | 340 | 60 | 0.8 | 2 | 300 |
OEF350 | 350 | 60 | 0.8 | 2 | 300 |
Metal Edge Formwork Data Sheet (Download)
