Flat Base Mesh Support

Flat Base Mesh Support

Offering similar characteristics to the Heavy Duty Flat Base Clip-On spacer for purely horizontal applications. The Type 1 spacer provides the largest base area of all the flat base spacers in the range, offering superior performance, stability and peace of mind when supporting mesh reinforcement above moisture and gas membranes. The large base distributes loads over a large
surface area minimising risk of perforation damage to the membrane.
Product Code Cover (mm) Bar Dia. (mm) Type Pack Size (no) Pallet Size (no)
FB1520 15 - 20 8-16 1 500 16000
FB2530 25 - 30 8-16 1 250 10000
FB4050 40 - 50 8-16 1 200 16000
FB5060 50 - 60 8-16 1 200 13600
FB7080 70 - 80 8-16 1 200 7200
FB90100 90 - 100 8-16 2 100 5000
