Magnetic Boxes enable a quick and secure fastening of the shuttering profile and built-in components. They contain a switchable magnet unit and by depressing the button on top the magnetic force is activated. In deactivated mode the magnet box is easy to position. The magnetic box can be equipped with various adapters and hold-down devices by means of the threaded holes integrated on the top of the box.
Profile:
40/25, 49/30, 54/33 & 72/49
Product Code | Adhesion (kg) | Length (mm) | Width (mm) | Height (mm) | Weight (kg) |
---|---|---|---|---|---|
WMB811 | 800 | 139 | 100 | 60 | 3.5 |
WMB911 | 1000 | 267 | 68 | 60 | 4.3 |
WMB1811 | 1800 | 267 | 104 | 60 | 7.3 |
WMB2112 | 2100 | 267 | 104 | 60 | 7.3 |
WMB2511 | 2400 | 267 | 133 | 70 | 9.7 |
Weckenmann Magnetic Box Data Sheet (Download)
