Uni Hammer-in Wall Tie

Used in conjunction with the Insulation Flex Plugs.

Finish: Grade 316 Stainless Steel

Embedment Depth Inner Leaf: min 40

Insertion Depth Outer Leaf: 45 to 75mm

Product Code	Cavity Size Max (mm)	Dia. (mm)	Length (mm)	Thread (mm)	Drill Dia. X Depth (mm)
IFPWT4160	55 +/- 15	4	160	4.6 x 35	6 x 50
IFPWT4190	85 +/- 15	4	190	4.6 x 35	6 x 50
IFPWT4220	115 +/- 15	4	220	4.6 x 60	6 x 50
IFPWT4250	145 +/- 15	4	250	4.6 x 60	6 x 50
IFPWT4275	170 +/- 15	4	275	4.6 x 60	6 x 50
IFPWT4300	195 +/- 15	4	300	4.6 x 60	6 x 50
IFPWT4325	220 +/- 15	4	325	4.6 x 60	6 x 50
IFPWT350	245 +/- 15	4	350	4.6 x 60	6 x 50
IFPWT375	270 +/- 15	4	375	4.6 x 60	6 x 50
IFPWT4400	295 +/- 15	4	400	4.6 x 60	6 x 50
IFPWT4425	320 +/- 15	4	425	4.6 x 60	6 x 50
IFPWT4450	345 +/- 15	4	450	4.6 x 60	6 x 50
IFPWT4475	370 +/- 15	4	475	4.6 x 60	6 x 50
IFPWT5250	145 +/- 15	5	250	6.0 x 37	8 x 50
IFPWT5275	170 +/- 15	5	275	6.0 x 37	8 x 50
IFPWT5300	195 +/- 15	5	300	6.0 x 37	8 x 50
IFPWT5325	220 +/- 15	5	325	6.0 x 37	8 x 50
IFPWT5350	245 +/- 15	5	350	6.0 x 37	8 x 50
IFPWT5375	275 +/- 15	5	375	6.0 x 37	8 x 50
IFPWT5400	295 +/- 15	5	400	6.0 x 37	8 x 50
IFPWT5425	320 +/- 15	5	425	6.0 x 37	8 x 50
IFPWT5450	345 +/- 15	5	450	6.0 x 37	8 x 50
IFPWT5475	370 +/- 15	5	475	6.0 x 37	8 x 50
IFPWT5500	395 +/- 15	5	500	6.0 x 37	8 x 50
IFPWT5525	420 +/- 15	5	525	6.0 x 37	8 x 50
IFPWT5550	445 +/- 15	5	550	6.0 x 37	8 x 50
IFPWT5575	470 +/- 15	5	575	6.0 x 37	8 x 50
IFPWT5600	495 +/- 15	5	600	6.0 x 37	8 x 50
