Straight Tail Lifting Sockets

Straight Tail Lifting Sockets

Manufactured from either high grade precision steel in zinc plated finish or stainless steel, and are supplied with an (Rd) round thread as standard. These sockets have an integral reinforcement bar attached. Designed for lifting very thin precast panels, the long ribbed anchorage reinforcement distributes loads evenly along its length, eliminating concentrated loads within the concrete during lifting.


Product Code Thread Dia. (Rd) Length (mm) Bar Dia (mm) SWL (kg) Pack Size Pallet Size
SLST12340 12 195 8 500 200 9000
SLST16500 16 270 12 1200 100 2500
SLST20600 20 350 14 2000 50 1600
SLST24720 24 450 16 2500 Each 360
SLST30840 30 505 20 4000 Each 500
SLST36980 36 680 25 6300 Each 200

Also available in stainless steel. (Add SS to Product Code)

  • Data Sheet

    Guidance on Choice of Socket (Download)

    Straight Tail Lifting Socket Data Sheet (Download)

  • Technical Manual

    Threaded Socket Technical Manual (Download)

  • Certificates

    UKCA Declaration of Conformace (Download)

    EU CE Declaration  of Conformance (Download)

    UK Test Certificate Example (Download)
