Square Support with Loop Ties
Square Support with Galvanised Loop Ties
Concrete spacer with galvanised loop ties and flat base support offer a very sturdy spacer.
Manufactured in accordance with BS7973-1 :2001.
Minimum Concrete Strength of 50N/mm2.
Approved according to DBV specification.
| Product Code | Cover (mm) | Bar Dia. (mm) | Pack Size (no) | Pallet Size (no) |
|---|---|---|---|---|
| CSLT20 | 20 | 6-30 | 440 | 17600 |
| CSLT25 | 25 | 6-30 | 325 | 13000 |
| CSLT30 | 30 | 6-30 | 295 | 11800 |
| CSLT40 | 40 | 6-30 | 185 | 7400 |
| CSLT50 | 50 | 6-30 | 150 | 6000 |
| CSLT55 | 55 | 6.-30 | 100 | 4000 |
| CSLT60 | 60 | 6-30 | 90 | 3600 |
| CSLT65 | 65 | 6-30 | 80 | 3200 |
| CSLT70 | 70 | 6-30 | 70 | 2800 |
| CSLT75 | 75 | 6-30 | 65 | 2600 |
| CSLT80 | 80 | 6-30 | 60 | 2400 |
