Spiral Oval Void Former
Spiral Void Formers are precisely manufactured, utilising the latest manufacturing techniques from cold rolled pre-galvanised steel strip, ensuring durability and longevity. They are ideal for extended outdoor storage without compromising the quality. If your project requires a specific thickness, we accommodate custom requests to meet your unique specifications.
Our void formers are conveniently stocked in 3-meter lengths as standard, providing flexibility in application. Additional convenience is provided with a cut-to-length service, minimising waste and tailoring the product to your site-specific needs.
✓ Any length available on request.
✓ Manufactured from galvanised steel, Zn coated 50-60 gsm. Tensile strength 315-430 MPa.
✓ Heavy Duty version available upon request.
✓ Rectangular version available upon request.
✓ Manufacture in the UK.
| Product Code | Internal Dia. (mm) | External Dia. (mm) | Rib Depth (mm) | Length (mm) |
|---|---|---|---|---|
| VFO055095 | 55 x 95 | 62 x 102 | 3.5 | 3000 |
| VFO060080 | 60 x 80 | 67 x 87 | 3.5 | 3000 |
| VFO060120 | 60 x 120 | 67 x 127 | 3.5 | 3000 |
| VFO070120 | 70 x 120 | 77 x 127 | 3.5 | 3000 |
| VFO085055 | 85 x 55 | 92 x 62 | 3.5 | 3000 |
| VFO090050 | 90 x 50 | 97 x 57 | 3.5 | 3000 |
| VFO110050 | 110 x 50 | 117 x 57 | 3.5 | 3000 |
| VFO115050 | 115 x 50 | 122 x 57 | 3.5 | 3000 |
| VFO12060 | 120 x 60 | 127 x 67 | 3.5 | 3000 |
| VFO12080 | 120 x 80 | 127 x 87 | 3.5 | 3000 |
