Short Wavy Tail Lifting Sockets

Short Wavy Tail Lifting Sockets

Manufactured from either high grade precision steel in zinc plated finish or stainless steel, and are supplied with an (Rd) round thread as standard. These sockets have an integral reinforcement bar attached.


Product Code Thread Dia. (Rd) Length (mm) Bar Dia (mm) SWL (kg) Pack Size Pallet Size
SLWS12108 12 108 8 500 300 8400
SLWS16167 16 167 12 1200 100 4000
SLWS20187 20 187 16 2000 50 2000
SLWS24240 24 240 16 2500 Each 2300
SLWS30300 30 300 20 4000 Each 1000
SLWS36380 36 380 25 6300 Each 660
SLWS42450 42 450 28 8000 Each 400

Also available in stainless steel. (Add SS to Product Code)

  • Data Sheet

    Guidance on Choice of Socket (Download)

    Short Wavy Tail Lifting Socket Data Sheet (Download)

  • Technical Manual

    Threaded Socket Technical Manual (Download)

  • Certificates

    UKCA Declaration of Conformace (Download)

    EU CE Declaration  of Conformance (Download)

    UK Test Certificate Example (Download)
