Heavy Duty Anchor Lifting Sockets

H.D Anchor Lifting Sockets

A system utilising conventional metric thread to provide a wider range of lifting capacities per thread size. Ideal for production facilities

wishing to rationalise stock items and reduce the range of lifting shackles required.


Product Code Thread Dia. (M) Length (mm) SWL (kg) Pack Size Pallet Size
SLHDA12070 12 70 1300 100 6000
SLHDA12130 12 130 1300 100 6000
SLHDA16090 16 90 2500 50 3000
SLHDA16140 16 140 2500 40 2400
SLHDA16200 16 200 2500 40 2400
SLHDA20125 20 125 4000 30 1800
SLHDA20258 20 258 4000 20 1200
SLHDA24140 24 140 5000 20 1200
SLHDA24325 24 325 5000 20 600
SLHDA30185 30 185 7500 15 720
SLHDA30400 30 400 7500 10 450
SLHDA36475 36 475 10000 5 250
SLHDA42550 42 550 12500 5 125
SLHDA52575 52 575 15000 5 100

Also available in stainless steel. (Add SS to Product Code)

  • Data Sheet

    Guidance on Choice of Socket (Download)

    Heavy Duty Anchor Lifting Socket Data Sheet (Download)

  • Technical Manual

    Threaded Socket Technical Manual (Download)

  • Certificates

    UKCA Declaration of Conformance (Download)

    EU CE Declaration of Conformance (Download)

    UK Test Certificate Example (Download)
