Flat End Lifting Sockets

Flat End Lifting Sockets

Manufactured from either high grade precision steel in zinc plated finish or stainless steel. The sockets are supplied with a metric (M) thread as standard. Euro Accessories Flat End Lifting Sockets provide a cost effective alternative to Tubular Lifting Sockets. They are used in the same manner and utilise identical cross hole reinforcement and lateral reinforcement as the Tubular Lifting Sockets.


Product Code Thread Dia. (M) Length (mm) SWL (kg) Pack Size Pallet Size
SLF1260 12 60 500 500 14000
SLF1680 16 80 1200 180 6000
SLF2095 20 95 2000 80 3840
SLF24100 24 100 2500 60 2400
SLF30135 30 135 4000 30 900

Also available in stainless steel. (Add SS to Product Code)

  • Data Sheet

    Guidance on Choice of Socket (Download)

    Flat End Lifting Socket Data Sheet (Download)

  • Technical Manual

    Threaded Socket Technical Manual (Download)

  • Certificates

    UKCA Declaration of Conformace (Download)

    EU CEDeclaration of Conformance (Download)

    UK Test Certificate Example (Download)
