Concrete Triangular Bar - 50N/mm2
Concrete Triangular Bar 50N/mm2
This triangular spacer has can be placed on any face to achieve the desired concrete cover. It can be
broken into smaller sections for use as individual supports.
Manufactured in accordance with BS7973-1 :2001.
| Product Code | Cover (mm) | Length (mtr) | Pallet Size (no) | Pallet Weight (kg) |
|---|---|---|---|---|
| CBT20 | 20 | 0.9 | 1400 | 1000 |
| CBT25 | 25 | 0.9 | 1200 | 980 |
| CBT30 | 30 | 0.9 | 1000 | 950 |
| CBT35 | 35 | 0.9 | 750 | 1000 |
| CBT40 | 40 | 0.9 | 600 | 1000 |
| CBT50 | 50 | 0.9 | 350 | 1050 |
| CBT60 | 60 | 0.9 | 280 | 1100 |
| CBT75 | 75 | 0.9 | 180 | 1100 |
