Bolt Anchor Lifting Sockets

Bolt Anchor Lifting Sockets

A non-preloaded bolting assembly for providing connections between structural steel stanchion bases and concrete foundations. These bolts are manufactured in accordance with BS 7419-2012 and are provided CE marked according to the requirements of BS EN 1504-1. They are provided in either grade 4.6 or 8.8 steel grades.


Product Code Thread Dia. (M) Length (mm) SWL (kg) Pack Size Pallet Size
SLBA1290 12 90 500 200 7200
SLBA12150 12 150 500 50 3000
SLBA16140 16 140 1200 50 3000
SLBA16220 16 220 1200 30 1800
SLBA20180 20 180 2000 20 1680
SLBA20270 20 270 2000 15 1080
SLBA24200 24 200 2500 15 900
SLBA24320 24 320 2500 10 600
SLBA30240 30 240 4000 8 480
SLBA30380 30 380 4000 5 350
SLBA36300 36 300 6300 5 300
SLBA36420 36 420 6300 5 250
SLBA42300 42 300 8000 2 200
SLBA42460 42 460 8000 2 140

Also available in stainless steel. (Add SS to Product Code)

  • Data Sheet

    Guidance on Choice of Socket (Download)

    Solid Rod Lifting Socket Data Sheet (Download)

  • Technical Manual

    Threaded Socket Technical Manual (Download)

  • Certificates

    UKCA Declaration of Conformace (Download)

    EU CE Declaration of Conformance (Download)

    UK Test Certificate Example (Download)
