Bolt Anchor Fixing Sockets

Bolt Anchor Fixing Sockets

A heavy duty fixing socket with an inverted 8.8 self-colour bolt for anchorage, matched to an S355J0 metric threaded structural steel connection.



Product Code Thread Dia (M) Length (mm) Load (kN) Pack Size Pallet Size
SFBA12055 12 55 9 200 7000
SFBA12150 12 150 18 100 7000
SFBA16075 16 75 13 100 7000
SFBA16220 16 220 27 50 3000
SFBA20090 20 90 18 50 3000
SFBA20270 20 270 42 20 1680
SFBA24200 24 200 58 20 1680
SFBA30240 30 240 76 10 600

Also available in stainless steel. (Add SS to Product Code)

  • Data Sheet

    Guidance on Choice of Socket (Download)

    Solid Rod Fixing Socket Data Sheet (Download)

  • Technical Manual

    Threaded Socket Technical Manual (Download)

  • Certificates

    UKCA Declaration of Conformance (Download)

    EU CE Declaration of Conformance (Download)

    UK Test Certificate Example (Download)
